BLN2PAB-SUPREMA-Lector de Huella IP67 Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR),NFC y BLUETOOTH, Certificado FBI PIV

SKU: BLN2PAB Categorías: Biométricos, Control de Acceso, Para Tiempo y Asistencia / Checadores Brand: SUPREMA

$22,873.81 MXN IVA incluido+ Envío Gratis

Agotado

Descripción

BioLite N2 Bluetooth y NFC

Terminal de Huella IP67 Para exterior Control de Accesos y Asistencias

Suprema, uno de los principales líderes biométricos en seguridad tecnológica, presenta uno de los mejores algoritmos biométricos con una ingeniería superior. Se encuentra constantemente desarrollando y produciendo productos líderes en la industria, extendiendo su portafolio de productos de control de acceso y tiempo y asistencia en todo el mundo.

Características Físicas y Eléctricas:

Pantalla: 1.77” TFT LCD.
Comunicación: TCP/IP..
Interfaz RS-485 para comunicación o módulo esclavo SIO2.
Salida de relevador.
Wiegand: entrada y salida. (seleccionable)
Certificados: CE, FCC, KC, RoHS, REACH, WEE.
Alimentación: 12 Vcc, 1 A (fuente no incluida)
Dimensiones: 155 x 155 x 40 mm.

Usuarios:

Usuarios (1:1) 10,000.
Usuarios (1:N) 10,000.
Plantillas (huellas) (1:1) 20,000.
Plantillas (huellas) (1:N) 20,000.
Eventos: 1 000 000.

Notas :

BLN2OAB Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR),NFC y BLUETOOTH.
Requiere de software BIOSTAR2 2.6 o superior (no incluido)

Visite nuestra Base de conocimiento de

SUPREMA

Specificationes

Scroll left/right

Model Name

Credential

RF Option
RF read range ²⁾
Mobile Card

Protections

IP rating
IK rating

Fingerprint

Template
Extractor / Matcher
Live Fingerprint Detection

Capacity

Max. User
Max. Credential (1:N)
Max. Credential (1:1)
Max. Text Log
Max. Image Log

General

CPU
Memory
Crypto Chip
LCD Type
LED
Sound
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Weight
Dimension (WxHxD, mm)
Certifications

Interface

Wi-Fi
Ethernet
RS-485
RS-485 Communication Protocol
Wiegand
TTL Input
Relay
USB
SD Card
PoE
Intercom
Tamper

Electrical

Power

BLN2-ODB

125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

BLN2-OAB

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, iCLASS SE/SR/Seos, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

BLN2-PAB

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, iCLASS SE/SR/Seos, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-10°C ~ 50°C (14°F ~ 122°F)

-20°C ~ 60°C (-4°F ~ 140°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

¹⁾DESFire EV2/EV3 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with BioLite N2.

²⁾RF read range will vary depending on installation environment.
